Model | X(S)N-10X32 | X(S)N-20X34 | X(S)N-35X30 | X(S)N-55X30 | X(S)N-75X30 | X(S)N-110X30 |
Total volume of mixing chamber | L | 25 | 45 | 75 | 125 | 180 | 250 |
Working volume of mixing chamber | L | 10 | 20 | 35 | 55 | 75 | 110 |
Driving motor power | KW | 15 | 22 | 55 45 | 75 55 | 110 95 | 185 |
Tilting motor power | KW | 1.1 | 1.5 | 2.2 | 2.2 | 4 | 4 |
Tilting angle | ° | 140 | 140 | 140 | 140 | 140 | 140 |
Rotational speed of the rotor(front/rear) | r/min | 32/23.5 | 34/28 | 30/24.5 | 30/24.5 | 30/24.5 | 30/24.5 |
Pressure of compressed air | MPa | 0.5~0.8 | 0.5~0.8 | 0.5~0.8 | 0.6~0.8 | 0.6~0.8 | 0.6~0.8 |
Capacity of compressed air | m3/min | ≥0.5 | ≥0.7 | ≥0.9 | ≥1.0 | ≥1.0 | ≥1.5 |
Pressure of cooling water(rubber mixing) | MPa | 0.2~0.4 | 0.2~0.4 | 0.3~0.4 | 0.3~0.4 | 0.3~0.4 | 0.3~0.4 |
Pressure of heating steam(plastics mixing) | MPa | 0.5~0.8 | 0.5~0.8 | 0.5~0.8 | 0.5~0.8 | 0.5~0.8 | 0.5~0.8 |
Overall dimensions | L | mm | 2580 | 2630 | 3200 | 3280 | 3330 | 3930 |
W | mm | 1300 | 1520 | 1900 | 1930 | 2620 | 3000 |
H | mm | 2280 | 2550 | 2950 | 3070 | 3340 | 3660 |
Weight | Kg | 3300 | 4500 | 6500 | 7500 | 10500 | 14500 |
