Details
Specifications
Product packaging
Spec | GE90KS×14D | GE120KS×14D | GE150KS×16D | GE200KS×18D | GE200KS×18D | GE250KS×14D |
Screw diameter |
| 90 | 120 | 150 | 200 | 200 | 250 |
L/D ratio |
| 14:1 | 14:1 | 16:1 | 18:1 | 12:1 | 12:1 |
Max. screw speed | r/min | 60 | 55 | 44 | 33 | 26 | 22.63 |
Hopper opening |
| 130×122 | 164×140 | 200×165 | 260×210 | 260×210 | 320×246 |
Row qty of pin |
| 8 | 10 | 10 | 12 | 10 | 10 |
Pin qty.of each row |
| 6 | 6 | 8 | 10 | 10 | 12 |
Model of motor |
| Z4-200-21 | Z4-200-31 | Z4-250-21 | Z4-280-32 | Z4-280-11 | Z4-280-32 |
Power | kW | 67 | 90 | 185 | 315 | 250 | 315 |
Zone of hot water circulation |
| 4 | 4 | 4 | 4 | 3 | 4 |
Max total power of hot water circulating heating | kW | 24 | 48 | 48 | 54 | 42 | 48 |
Capacity | /h | 360 | 800-1000 | 1800-2000 | 2100-2600 | 2300 | 3000 |
Overall dimensions | L | mm | 2540 | 3996 | 6000 | 7770 | 6250 | 6885 |
W | mm | 1493 | 1575 | 2600 | 3000 | 3000 | 2400 |
H | mm | 1416 | 1760 | 1800 | 2035 | 2035 | 2090 |
{}
